9 Cylinder Thottleable 4 stroke Radial Collision Engine

Image:
screenshot of the scene

Author: Gent

Group: Default

Filesize: 286.16 kB

Date added: 2012-04-27

Rating: 7.1

Downloads: 2350

Views: 836

Comments: 6

Ratings: 6

Times favored: 0

Made with: Algodoo v2.0.2 Edu

Tags:

Scene tag

New version for Algodoo 2.0+
I made some improvements, getting 34 rad/s no load ;)

This started as a model of the Pratt & Whitney R985 which has a bore
and stroke of 132mm. I couldnt get that close so this is a 948 @ 130 LOL

Features: fully throttleable, educational color coded strokes (like all my
4 stroke engines) and mostly accurate valve timing. Also the load can
be varried by turning air friction on and off and changing the value in
the options, it will pull 10x air friction The prop tips have air friction
multiplyer of 500 so its making quite a bit of power!
Cylinders are numbered counter clockwise from top center.
Firing order:1,3,5,7,9,2,4,6,8

Credits once again to Kilinich for the Conundrummer gear generator!

This WILL lag on slower computers but for some reason it shows higher
rad/s in the plot on slower comps?
Algodoo only, uses lasers!

Controlls in scene.

Please comment and rate!
