Heat Pipe

Image:
screenshot of the scene

Author: s_noonan

Group: Technical

Filesize: 258.37 kB

Date added: 2013-06-10

Rating: 5

Downloads: 1286

Views: 296

Comments: 2

Ratings: 1

Times favored: 0

Made with: Algodoo v2.1.0

Tags:
heat

Scene tag

A tubular device that is very efficient in transferring heat. Using a metal container (aluminum, copper, etc.) that holds a liquid (water, acetone, etc.) under pressure, the inner surface of the tube is lined with a porous material that acts as a wick. When heat is applied to the outer area of the tube, the liquid inside the tube boils and vaporizes into a gas that moves through the tube seeking a cooler location where it condenses. Using capillary action, the wick transports the condensed liquid back to the evaporation area.

More info can be found here or here.
Last edited at 2016/07/02 20:47:27 by s_noonan
