Divide by 3

Image:
screenshot of the scene

Author: jon_joy_1999

Group: Default

Filesize: 76.59 kB

Date added: 2012-12-05

Rating: 5

Downloads: 769

Views: 576

Comments: 2

Ratings: 1

Times favored: 0

Made with: Algodoo before v1.8.5

Tags:

Scene tag
this device outputs 1 for every 3 cycles of the input. I've built a rudimentary oscilloscope to easily observe this behavior. the logic is active-low, so it's counting down-pulses, not up-pulses. to be specific, for every 3 red down-pulses, there will be 1 aqua down-pulse that will hold down until the next down pulse, in a red red aqua red red aqua pattern
