PID Control

Image:
screenshot of the scene

Author: Kurthew

Group: Default

Filesize: 11.28 kB

Date added: 2012-05-04

Rating: 5.6

Downloads: 371

Views: 895

Comments: 3

Ratings: 2

Times favored: 0

Made with: Algodoo v2.0.1 Edu

Tags:

Scene tag
A simple example of PID (Proportion, integral, and derivative) control. See if you can adjust the gains (Kp, Ki, and Kd) so that you get little or no bounce. Or don't. Either way, enjoy!

Controls:
Up - increase Kp
Down - decrease Kp
Right - increase Kd
Left - decrease Kd
\ - increase Ki
] - decrease Ki
/ - increase Altitude
. - decrease Altitude
, - reset Altitude back to '5'
return - set all gains back to '0'
shift - toggle thruster
