3D CNC Router

Image:
screenshot of the scene

Author: Antotabo

Group: Default

Filesize: 106.54 kB

Date added: 2010-02-11

Rating: 9

Downloads: 26871

Views: 6608

Comments: 20

Ratings: 32

Times favored: 3

Made with: Phun

Tags:
router,
milling,
router milling ,
numerical contr,
robot,
program,
machine,
automated,
isometric,
perspective

(Show all)

Scene tag

This is a typical CNC router setup. You can really cut material manually or run the toolpath contained in scene.my.gcode.

The tool path actually loaded make a nice pyramid. The origin of the code is on the top center of the workpiece. so you have to jog to this point andpress x, y, z to make this position the origin.

But you can make your really own program and load them in the console.

G-code template to make your program:

scene.my.gcode=[[0,0,0],[0,0,0],[0,0,0],[0,0,0],[0-
,0,0],[0,0,0],
[0,0,0],[0,0,0],[0,0,0],[0,0,0],[0,0,0],[0,0,-
0],[0,0,0],
[0,0,0],[0,0,0],[0,0,0],[0,0,0],[0,0,0],[0,0,0],-
[0,0,0]]

Controls:

Start Spindle : S key
Zero X : X key
Zero Y : Y key
Zero Z : Z key

Start CNC program : Enter Key

Manual Jog:

X: up and down arrow keys
Y: left and right arrow keys
Z: page up and page down keys

Post your g-codes in the comments, I would like to see some!

Update: Real looking EndMill. Special thanks to Legophunpp for the idea. Press S to start the spindle.
Last edited at 2010/05/20 05:21:58 by Antotabo
Please log in to rate this scene
edit
