Horizontal Steam Engine with Stephenson's Link Valve Gear

Image:
screenshot of the scene

Author: HoverGuy

Group: Default

Filesize: 83.72 kB

Date added: 2018-05-15

Rating: 5.6

Downloads: 2379

Views: 598

Comments: 1

Ratings: 2

Times favored: 1

Made with: Algodoo v2.1.0

Tags:

Scene tag
I've been interested in steam engines for about half a year now.
So I built [another] one in Algodoo.

Single cylinder, slide valve, actuated by Stephenson's valve gear.
Use up and down arrows to move the reversing lever up/down
(forward/reverse).
If the engine doesn't start, (which hasn't happened to me yet)
give the flywheel a little push with the drag tool.
