8-bit mechanical calculator

Image:
screenshot of the scene

Author: Ravenplucker

Group: Technical

Filesize: 378.68 kB

Date added: 2016-07-20

Rating: 7.3

Downloads: 4509

Views: 512

Comments: 5

Ratings: 7

Times favored: 0

Made with: Algodoo v2.1.0

Tags:
mechanical,
clockwork,
mechanics,
calculator,
adder,
computer,
full adder,
circuit,
memory

Scene tag

It's just an adder, but "calculator" sounds so much better.
~Completely mechanical~

Press S to add the 2 numbers and display the result in binary.
Press R to reset
I provided some numbers (which I *think* I did correctly) but you can make your own if you're feeling ADVENTUROUS.

Works from 100-300Hz. Can't be bothered tweaking at this point, I'll make an improved one later probably.

I tried to make this one both fast and small. At 100Hz it produces an output in about 3.5 seconds, and it takes up less than a metre square.

Uses rod-logic to make logic gates, which in turn makes 8 full adders in series. (I could have replaced the first with a half adder, but by the time I realised that I couldn't be bothered). The rods are pushed in the correct sequence using a central cam in each full adder. One half of a turn pushes all the rods, and the other half resets them in the correct order.



I stole the binary-reading explanation off Rastamoose c:

Related reading: Conundrumer made a bunch of counters using rod logic. http://www.algodoo.com/algobox/details.php?id=62815

This shows some basic gates using rod logic
http://www.halfbakedmaker.org/blog/58

A lot longer, but is interesting reading even if the maths goes right over your head (like it does mine).
http://www.zyvex.com/nanotech/mechano.html

EDIT: slightly tweaked
Last edited at 2016/07/21 00:13:49 by Ravenplucker
Please log in to rate this scene
edit
Similar scenes
Title: 15-bit binary calculator
Rating: 2.5
Filesize: 380.44 kB
Downloads: 613
Comments: 1
Ratings: 2
Date added: 2008/11/25 21:32:49
Made with: Phun
Rating: rated 2.5
download
Title: Mechanical binary adder
Rating: 6.5
Filesize: 232.47 kB
Downloads: 1356
Comments: 5
Ratings: 4
Date added: 2013/11/25 16:36:45
Made with: Algodoo v2.1.0
Rating: rated 6.5
download
Title: Reusable 4-Bit Binary Adder [Algodoo only]
Rating: 5
Filesize: 43.72 kB
Downloads: 958
Comments: 3
Ratings: 1
Date added: 2010/11/24 01:07:35
Made with: Algodoo before v1.8.5
Rating: rated 5
download
Title: Full Adder
Rating: 6.6
Filesize: 210.5 kB
Downloads: 269
Comments: 1
Ratings: 5
Date added: 2009/01/14 12:20:35
Made with: Phun
Rating: rated 6.6
download
Title: 4 bit mechanical adder
Rating: 6.7273
Filesize: 153.29 kB
Downloads: 1628
Comments: 4
Ratings: 5
Date added: 2014/12/17 04:28:21
Made with: Algodoo before v1.8.5
Rating: rated 6.7
download
Title: full adder with 7 segment display
Rating: 5
Filesize: 148.43 kB
Downloads: 364
Comments: 0
Ratings: 1
Date added: 2016/01/24 01:15:11
Made with: Algodoo v2.1.0
Rating: rated 5
download
This is an awesome machine (as usual), but there seems to be a problem. After I do the first addition, and then Reset, the newly added balls just disappear when I drop them into the machine. :huh:
Ooh, weird. I think I've fixed it now.
I think it was the balls clipping through the bar blocking them from the Killer plate below. I lowered the bar and extended the blocker slightly and it seems to be all g (assuming the ball isn't dropped from a huge height)
Last edited at 2016/07/21 00:20:14 by Ravenplucker
Works good now!:tup:
You are the best!
This is awesome, so much cooler than mine:D
As always, your machines never fail to impress me. I always have such respect for these scenes with no scripting.
