3-bit binary sorter

Image:
screenshot of the scene

Author: Ravenplucker

Group: Technical

Filesize: 120 kB

Date added: 2016-04-13

Rating: 7.5

Downloads: 3632

Views: 620

Comments: 14

Ratings: 8

Times favored: 0

Made with: Algodoo v2.1.0

Tags:

Scene tag

Another automatic scene. This machine sorts a stack of 24 boxes into 8 groups based on the 3 bit number in each box, represented by a line of 3 squares which either collide or don't collide with the reader.

It's my first proper attempt at figuring out how to do mechanical binary stuff.

Rate and comment pls

EDIT: fixed a couple of bugs that stopped it working up at a higher frequency.

EDIT2: Accidentally uploaded it running at 700Hz, when it runs fine at 100 :o
